Cámara de Seguridad Panasonic AW-UE80W/K

Sobre este producto

• 🌐 Cámara de Seguridad Panasonic AW-UE80W/K: para videovigilancia y seguridad.
• ✅ NDI|HX, 3G-SDI, HDMI
• ✅ Conference camera
• ✅ color (Day&Night)

Característica	Detalle
Marca	Panasonic
Línea de producto	Panasonic
Modelo	AW-UE80W/K
Fabricante	Panasonic Industrial
Protocols	ARP, DDNS, DHCP, DHCPv6, DNS, HTTP, HTTPS, ICMP, IGMP, MLD, NDI, NTP, RTMP, RTMPS, RTP, RTSP, SRT, TCP/IP, UDP/IP
Connectivity Technology	Wired
Ports	3G-SDI output - BNC, Audio line in - 3.5 mm jack, G/L input - BNC, HDMI output, LAN - RJ-45, Serial RS-232 - RJ-45
Image Sensor Size	1/2.5"
Image Sensor Type	MOS
Touchscreen	No
Audio Formats	AAC-LC
Audio Support	Yes
Camera Mechanical Design	Pan / tilt / zoom
Control Interface	RS-232
Digital Video Capture Resolution	1280 x 720, 1920 x 1080, 3840 x 2160
Digital Zoom	36
Horizontal Resolution (TV Lines)	1500
Max Frame Rate	30 frames per second
Max Panning Speed (degree/sec)	180
Max Tilting Speed (degree/sec)	180
Max Video Resolution	3840 x 2160
Panning Range (degree)	-175 to +175
Recording Formats	JPEG
Shutter Speed (Max)	1/10000 second (time unit)
Shutter Speed (Min)	1/25 second (time unit)
Still Image Capture Resolution	1280 x 720, 1920 x 1080, 320 x 180, 640 x 360
Video Modes	1080/23.98p, 1080/23.98PsF, 1080/24p, 1080/25p, 1080/25PsF, 1080/29.97PsF, 1080/30p, 1080/50i, 1080/50p, 1080/59.94i, 1080/59.94p, 2160/23.98p, 2160/24p, 2160/25p, 2160/29.97p, 2160/50p, 2160/59.94p, 4K/50p, 4K/60p, 720/50p, 720/59.94p
Video Signals	3G-SDI, HDMI, NDI|HX
Camera Mount Type	Ceiling mount, Surface mount
Camera Type	Conference camera
Night Vision	Yes
Low Voltage Power	DC 10.8 - 13.2 V / PoE++
Angular Field of View (D, Max, Degree)	81.8
Angular Field of View (D, Min, Degree)	3.8
Angular Field of View (H, Max, Degree)	74.1
Angular Field of View (H, Min, Degree)	3.3
Angular Field of View (V, Max, Degree)	46
Angular Field of View (V, Min, Degree)	1.9
Focal Length Control	Motorized zoom
Focus Modes	Automatic, Manual
Lens Aperture	F/1.8-4
Max Focal Length	98.9 millimetre
Temp. máx. de operación	104 degree Fahrenheit
Min Focal Length	4.12 millimetre
Min Focus Distance	3.9 inch
Temp. mín. de operación	32 degree Fahrenheit
Minimum Illumination	3 lux F1.8 - 50 IRE
Humedad de operación	20 - 90% (non-condensing)
Operating System Required	Apple macOS 10.14, Apple macOS 10.15, Apple macOS 11.0.1, Windows 10, Windows 11
Optical Zoom	24
Sensor Size (metric)	10.2 mm (1/2.5")
Supported Host Device Platform	Android, iOS, MacOS, Windows
Video Formats	H.264, H.265, MJPEG
Video Input	Color
Características	Auto tracking, Automatic Tracing White (ATW), Automatic Whiteness Balance (AWB), Black Burst Sync (BBS), Tri-level sync supported, Tripod support
Cantidad por empaque	1
Alto	8.3 inch
Weight	4.41 lbs
Ancho	6.7 inch
Profundidad	6.7 inch
Color	Pearl white
Color	White
Estándares	IEEE 802.3bt
