Cámara de Seguridad i-PRO S-Series WV-S22700-V2L

Sobre este producto

• 📹 Resolución 4K en cámara dome para interior
• 🔍 Lente con zoom motorizado y amplio ángulo de visión
• 🌙 Infrarrojo hasta 50 m en oscuridad total
• 🧠 Procesador Ambarella CV22 con analíticas por IA
• 🔊 Audio bidireccional y conectividad LAN
• 🛡️ Carcasa antivandálica; compresión H.264/H.265/MJPEG

Característica	Detalle
Marca	i-Pro
Línea de producto	i-PRO S-Series
Modelo	WV-S22700-V2L
Fabricante	i-PRO Americas
Memory Cards Supported	microSD Card, microSDHC Card, microSDXC Card
Network Interface	Ethernet 10Base-T/100Base-TX
Protocols	ARP, DDNS, DHCP, DHCPv6, DNS, HTTP, HTTPS, ICMP, IGMP, IPv6, LLDP, MLD, MQTT, NTP, RTCP, RTP, RTSP, SFTP, SMTP, SNMP 1, SNMP 2, SNMP 3, SRTP, SSL, TCP/IP, TLS, UDP/IP, UPnP
Connectivity Technology	Wired
Ports	Audio line in - 3.5 mm stereo jack, Audio line out - 3.5 mm stereo jack, LAN - RJ-45, Video output
Image Sensor Size	1/1.8"
Image Sensor Type	CMOS
Tilt	-30 to +85
Touchscreen	No
Audio Formats	AAC-LC, ADPCM, G.711, G.726
Audio Support	Yes
Audio Support Features	Two-way audio capability
Camera Mechanical Design	Pan / tilt / zoom
Digital Video Capture Resolution	1280 x 720, 1920 x 1080, 2560 x 1440, 320 x 180, 3840 x 2160, 640 x 360
Max Frame Rate	30 frames per second
Max Video Resolution	3840 x 2160
Motion Detection	Yes
Panning Range (degree)	-240 to 120
Recording Formats	JPEG
Shutter Speed (Max)	1/10000 second (time unit)
Shutter Speed (Min)	1/25 second (time unit)
Video Modes	4K
Camera Type	Network surveillance camera
Night Vision	Yes
Low Voltage Power	DC 12 V / PoE Class 0
Angular Field of View (H, Max, Degree)	101
Angular Field of View (H, Min, Degree)	52
Angular Field of View (V, Max, Degree)	55
Angular Field of View (V, Min, Degree)	29
Encryption	FIPS 140-2 Level 3
Focal Length Control	Motorized zoom
Focus Modes	Motorized
Factor de forma	Dome
Indoor/Outdoor	Indoor
Infrared Distance	164 ft
Infrared LEDs	Yes
Lens Aperture	F/1.5
Max Focal Length	8.6 millimetre
Temp. máx. de operación	122 degree Fahrenheit
Min Focal Length	4.3 millimetre
Min Focus Distance	3.3 ft
Temp. mín. de operación	14 degree Fahrenheit
Minimum Illumination	0 lux - B&W - F1.5 - 50 IRE - shutter 1/30 sec / infrared LEDs on, 0.03 lux - B&W - F1.5 - 50 IRE - shutter 1/30 sec, 0.04 lux - color - F1.5 - 30 IRE - shutter 1/30 sec, 0.06 lux - color - F1.5 - 50 IRE - shutter 1/30 sec
Humedad de operación	10 - 90% (non-condensing)
Optical Zoom	2
Protection	Vandal-proof
Sensor Size (metric)	14.1 mm (1/1.8")
Video Formats	H.264, H.265, MJPEG, NTSC, PAL
Video Input	Color
Alarm Input Quantity	3
Características	16:9 aspect ratio, 180° image rotation, 270° image rotation, 4:3 aspect ratio, 8 privacy zones, 90° image rotation, Adaptive Black Stretch (ABS), AI Analytics, AI Engine, AI face detection, AI non mask detection, AI occupancy detection, AI Sound Classification, AI vehicle detection, Alteration detection, Ambarella CV22 CPU, Audio alarm, Audio Detection, Auto ICR, Automatic Gain Control (AGC), Automatic Tracing White (ATW), Automatic White Balance Control (AWC), Backlight Compensation (BLC), Brute force delay protection, Constant Bit Rate (CBR), Device Certificate GlobalSign pre-installed, Digest authentication, Digital Noise Reduction, DORI coverage, E-mail alerts, Fog compensation, Full duplex audio, Half duplex audio, Highlight Compensation (HLC), Host authentication, Image transmission log, Intelligent Auto (iA), ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, People Detection, Polycarbonate bubble, Scene Change Detection (SCD), Signed firmware, Stainless steel housing, Super Dynamic technology, System log, User authentication, Variable Bit Rate (VBR), Variable Image Quality on Specified area (VIQS)
Cantidad por empaque	1
Alto	4 inch
Weight	28.22 ounce
Ancho	5.1 inch
Profundidad	5.1 inch
Color	White
Color	White
Estándares	CSA C22.2 No. 62368-1, EN 55032 Class A, EN 55035, FCC Part 15 A, ICES-003 Class A, IEC 62262 IK10, IEC 62368-1, IEEE 802.3af, NDAA, UL 62368-1
